+> 弱网环境为了支持 bbr、aufs，建议安装 linux-image-extra 内核, 参考：[Linux 升级 kernel 及 tcp_BBR](http://blog.dongcj.com/linux/Linux%E5%8D%87%E7%BA%A7kernel%E5%8F%8Atcp_BBR/)
|
|
|
+
|
|
|
+# 1. Ubuntu 安装 Docker
|
|
|
+## 1.1. install docker(latest)
|
|
|
+```bash
|
|
|
+# clone 后直接脚本安装 , CentOS 没有测试过
|
|
|
+git clone https://github.com/rancher/install-docker.git
|
|
|
+cd ./install-docker
|
|
|
+```
|
|
|
+
|
|
|
+## 1.2. install docker(previous release)
|
|
|
+```bash
|
|
|
+# if you want install pre version
|
|
|
+# add the repo to the apt
|
|
|
+deb [arch=amd64] https://download.docker.com/linux/ubuntu zesty stable
|
|
|
+deb-src [arch=amd64] https://download.docker.com/linux/ubuntu zesty stable
|
|
|
+
|
|
|
+# show the version avaiable
|
|
|
+apt update
|
|
|
+apt-cache madison docker-ce
|
|
|
+
|
|
|
+# install the specify docker release
|
|
|
+apt install docker-ce=17.06.2~ce-0~ubuntu
|
|
|
+```
|
|
|
+
|
|
|
+# 2. 配置 Docker 加速器（用于国内加速，可选）
|
|
|
+> 以下操作需重启 Docker 服务生效
|
|
|
+
|
|
|
+vi /etc/docker/daemon.json
|
|
|
+
|
|
|
+```json
|
|
|
+{
|
|
|
+ "registry-mirrors": [
|
|
|
+ "https://2lqq34jg.mirror.aliyuncs.com",
|
|
|
+ "https://pee6w651.mirror.aliyuncs.com",
|
|
|
+ "https://registry.docker-cn.com",
|
|
|
+ "http://hub-mirror.c.163.com"
|
|
|
+ ]
|
|
|
+}
|
|
|
+```
|
|
|
+
|
|
|
+<!-- more -->
|
|
|
+
|
|
|
+# 3. 配置 Docker 代理（国内无法访问国外某些网站的 https，可选）
|
|
|
+
|
|
|
+```
|
|
|
+# 临时使用直接启动 dockerd（当然也可以写入 systemd 长期生效）
|
|
|
+http_proxy=PROXY_ADDR:PORT https_proxy=PROXY_ADDR:PORT dockerd
|
|
|
+```
|
|
|
+
|
|
|
+# 4. 安装 docker-compose（可选）
|
|
|
+
|
|
|
+```bash
|
|
|
+# docker-compose VERSION:
|
|
|
+# https://github.com/docker/compose/releases
|
|
|
+
|
|
|
+# get the latest info
|
|
|
+DOCKER_COMPOSE_ARCH=docker-compose-Linux
|
|
|
+curl -s https://api.github.com/repos/docker/compose/releases/latest | \
|
|
|
+ jq -r ".assets[] | select(.name | test(\"${DOCKER_COMPOSE_ARCH}\")) | .browser_download_url"
|
|
|
+
|
|
|
+# download the latest version
|
|
|
+dockerComposeVersion=1.18.0
|
|
|
+
|
|
|
+curl -L https://github.com/docker/compose/releases/download/$dockerComposeVersion/docker-compose-`uname -s`-`uname -m` > /usr/local/bin/docker-compose
|
|
|
+
|
|
|
+sudo chmod +x /usr/local/bin/docker-compose
|
|
|
+docker-compose --version
|
|
|
+```
|
|
|
+
|
|
|
+# 5. 安装 docker-machine（可选）
|
|
|
+
|
|
|
+```bash
|
|
|
+curl -L https://github.com/docker/machine/releases/download/v0.9.0/docker-machine-`uname -s`-`uname -m` >/tmp/docker-machine
|
|
|
+chmod +x /tmp/docker-machine
|
|
|
+cp /tmp/docker-machine /usr/local/bin/docker-machine
|
|
|
+
|
|
|
+# 使用 docker-machine( 支持 virtualbox、阿里云等 )
|
|
|
+# 所有的 Available driver plugins：
|
|
|
+> https://github.com/docker/docker.github.io/blob/master/machine/AVAILABLE_DRIVER_PLUGINS.md
|
|
|
+
|
|
|
+# create aws machine
|
|
|
+docker-machine create --driver amazonec2 --amazonec2-access-key AKI******* --amazonec2-secret-key 8T93C******* aws-sandbox
|
|
|
+
|
|
|
+# 直接使用本地服务器
|
|
|
+docker-machine create --driver none --url=tcp://192.168.1.112:2376 svi1r01n02
|
|
|
+```
|
|
|
+
|
|
|
+# 6. Docker 常用配置
|
|
|
+> 如果是 systemctl 启动的 docker, 需要在 /lib/systemd/system/docker.service 中修改
|
|
|
+
|
|
|
+```bash
|
|
|
+## 配置 Docker 启动参数：（在 /etc/default/docker 中）
|
|
|
+DOCKER_OPTS="--storage-driver=aufs --tls=true --tlscert=/var/docker/server.pem --tlskey=/var/docker/serverkey.pem -H tcp://192.168.1.112:2376"
|
|
|
+
|
|
|
+other_args="--exec-driver=lxc \
|
|
|
+ --selinux-enabled [-H tcp://0.0.0.0:2376] [-b=br0]" # 如果用了 -H，连接时也要用 -H 指定 !!
|
|
|
+```
|
|
|
+
|
|
|
+## 6.1. Docker 使用不同的桥接方式
|
|
|
+
|
|
|
+```bash
|
|
|
+# 前台启动
|
|
|
+docker -d -b br0
|
|
|
+
|
|
|
+# 加入默认选项以使 service 生效
|
|
|
+other_args="--exec-driver=lxc --selinux-enabled -b=br0"
|
|
|
+```
|
|
|
+
|
|
|
+## 6.2. Docker 直接使用外部块存储
|
|
|
+> 映射为 container 内部盘，可以自定义使用 read、write、mknode 操作
|
|
|
+
|
|
|
+ docker run --device=/dev/sdc:/dev/xvdc:[rwm] --device=/dev/sdd --device=/dev/zero:/dev/nulo -i -t ubuntu ls -l /dev/{xvdc,sdd,nulo}
|
|
|
+
|
|
|
+## 6.3. Restart policies
|
|
|
+ docker run --restart=[always|no|on-failure|unless-stopped] redis
|
|
|
+
|
|
|
+## 6.4. 向容器中增加主机名与 IP 对应 (add /etc/hosts entry)
|
|
|
+ docker run --add-host=docker:10.180.0.1 --rm -it debian
|
|
|
+
|
|
|
+## 6.5. 设置容器的 ulimit
|
|
|
+ docker run --ulimit nofile=1024:1024 --rm debian sh -c "ulimit -n"
|
|
|
+
|
|
|
+## 6.6. Docker 重启 daemon 不重启 container
|
|
|
+```bash
|
|
|
+# 以下二种方法任一种都可以
|
|
|
+ - 将 /etc/docker/daemon.json 中的 "live-restore" 设置为 true，然后 SIGHUP（kill -HUP PID）
|
|
|
+ - sudo dockerd --live-restore
|
|
|
+```
|
|
|
+
|
|
|
+## 6.7. Docker Daemon 的配置文件
|
|
|
+> 可以使用 --config-file 指定，默认位置为 /etc/docker/daemon.json
|
|
|
+```json
|
|
|
+{
|
|
|
+ "authorization-plugins": [],
|
|
|
+ "bridge": "",
|
|
|
+ "cluster-advertise": "",
|
|
|
+ "cluster-store": "",
|
|
|
+ "debug": true,
|
|
|
+ "default-ulimits": {},
|
|
|
+ "disable-legacy-registry": false,
|
|
|
+ "dns": [],
|
|
|
+ "dns-opts": [],
|
|
|
+ "dns-search": [],
|
|
|
+ "exec-opts": [],
|
|
|
+ "fixed-cidr": "",
|
|
|
+ "graph": "",
|
|
|
+ "group": "",
|
|
|
+ "hosts": [],
|
|
|
+ "insecure-registries": [],
|
|
|
+ "labels": [],
|
|
|
+ "live-restore": true,
|
|
|
+ "log-driver": "",
|
|
|
+ "log-level": "",
|
|
|
+ "mtu": 0,
|
|
|
+ "pidfile": "",
|
|
|
+ "raw-logs": false,
|
|
|
+ "registry-mirrors": [],
|
|
|
+ "storage-driver": "",
|
|
|
+ "storage-opts": [],
|
|
|
+ "swarm-default-advertise-addr": "",
|
|
|
+ "tlscacert": "",
|
|
|
+ "tlscert": "",
|
|
|
+ "tlskey": "",
|
|
|
+ "tlsverify": true
|
|
|
+}
|
|
|
+```
|
|
|
+
|
|
|
+# 7. Docker 的 API 操作
|
|
|
+```bash
|
|
|
+# 镜像
|
|
|
+curl --unix-socket /var/run/docker.sock http://localhost/images/json
|
|
|
+
|
|
|
+# events
|
|
|
+curl --no-buffer -XGET --unix-socket /var/run/docker.sock http://localhost/events
|
|
|
+
|
|
|
+# container 信息
|
|
|
+curl --unix-socket /var/run/docker.sock "http://localhost/containers/json?all=1&before=8dfafdbc3a40&size=1"
|
|
|
+```
|
|
|
+
|
|
|
+# 8. Docker 小技巧
|
|
|
+
|
|
|
+## 8.1. 已运行容器通过 iptbles 来 nat
|
|
|
+
|
|
|
+ # Filter
|
|
|
+ iptables -A DOCKER -d 0.0.0.0 ! -i docker0 -o docker0 -p tcp -m tcp --dport 3306 -j ACCEPT
|
|
|
+ iptables -A DOCKER -p tcp -m tcp --dport 3306 -j ACCEPT
|
|
|
+
|
|
|
+ # DOCKER DNAT
|
|
|
+ iptables -t nat -A DOCKER -p tcp --dport 3306 -j DNAT --to-destination 172.16.19.2:3306
|
|
|
+
|
|
|
+
|
|
|
+ # POSTROUTING
|
|
|
+ iptables -t nat -A POSTROUTING -s 172.16.19.0/16 -d 172.16.19.0/16 -p tcp -m tcp --dport 3306 -j MASQUERADE
|
|
|
+ iptables -t nat -A POSTROUTING -p tcp -m tcp --dport 3306 -j MASQUERADE
|
|
|
+
|
|
|
+
|
|
|
+
|
|
|
+## 8.2. set metadata on container
|
|
|
+
|
|
|
+```bash
|
|
|
+# ( 如下设置了一个 my-label="" 和 com.example.foo=bar)
|
|
|
+docker run -l my-label --label com.example.foo=bar ubuntu bash
|
|
|
+docker run --label-file ./labels ubuntu bash
|
|
|
+
|
|
|
+# cat ./labels
|
|
|
+com.example.label1="a label"
|
|
|
+
|
|
|
+# this is a comment
|
|
|
+com.example.label2=another\ label
|
|
|
+com.example.label3
|
|
|
+```
|
|
|
+
|
|
|
+## 8.3. 直接设置 sysctl( 不能与 --network=host 同用 )
|
|
|
+ docker run --sysctl net.ipv4.ip_forward=1 ubuntu
|
|
|
+
|
|
|
+## 8.4. 从 container 的变化中新建一个 image
|
|
|
+ docker commit $CONTAINER_ID [REPOSITORY[:TAG]]
|
|
|
+
|
|
|
+
|
|
|
+## 8.5. 备份容器中的数据（将容器中的数据目录拷贝至当前目录下）
|
|
|
+ docker run --rm --volume-from dbdata -v ${pwd}:/backup ubuntu tar cvf /backup/backup.tar /dbdata
|
|
|
+
|
|
|
+
|
|
|
+# 9. Docker Inspect
|
|
|
+```bash
|
|
|
+# 如果镜像和实例名字重名，使用 --type 区分
|
|
|
+docker inspect --type=image rhel7
|
|
|
+
|
|
|
+# 获取正在运行的容器 IP 的示例
|
|
|
+container_ip=$(docker inspect --format '{{.NetworkSettings.IPAddress}}' ${container_id})
|
|
|
+
|
|
|
+# docker inspect 输出结果的解析
|
|
|
+docker inspect `docker ps -q` | grep IPAddress | cut -d '"' -f 4
|
|
|
+# 或者
|
|
|
+docker inspect `dl` | jq -r '.[0].NetworkSettings.IPAddress'
|
|
|
+
|
|
|
+# get the IP address of a container
|
|
|
+docker inspect \
|
|
|
+ --format='{{range .NetworkSettings.Networks}}{{.IPAddress}}{{end}}' \
|
|
|
+ d2cc496561d6
|
|
|
+
|
|
|
+172.17.0.2
|
|
|
+
|
|
|
+# 以 json 的格式展示
|
|
|
+docker inspect --format '{{json .Mounts}}' pensive_blackwell
|
|
|
+
|
|
|
+# 大小写
|
|
|
+docker inspect --format "{{lower .Name}}" pensive_blackwell
|
|
|
+
|
|
|
+# Listing all port bindings
|
|
|
+docker inspect \
|
|
|
+ --format='{{range $p, $conf := .NetworkSettings.Ports}} \
|
|
|
+ {{$p}} -> {{(index $conf 0).HostPort}} {{end}}' \
|
|
|
+ d2cc496561d6
|
|
|
+
|
|
|
+ 80/tcp -> 80
|
|
|
+
|
|
|
+# Getting size information on a container
|
|
|
+docker inspect -s d2cc496561d6 | grep -i Size
|
|
|
+
|
|
|
+# 找到 container 的 pid
|
|
|
+PID=$(docker inspect --format {{.State.Pid}} <container_name_or_ID>)
|
|
|
+
|
|
|
+# 找到 container 使用的镜像
|
|
|
+docker inspect -f '{{.Config.Image}}' 5cf58382b2f0
|
|
|
+
|
|
|
+# logging driver
|
|
|
+docker inspect -f '{{.HostConfig.LogConfig.Type}}' <CONTAINER>
|
|
|
+
|
|
|
+# 格式 host:port , 并且把他们输入一个 java properties 文件：
|
|
|
+sut_ip=${BOOT_2_DOCKER_HOST_IP}
|
|
|
+
|
|
|
+template='{{ range $key, $value := .NetworkSettings.Ports }}{{ $key }}='"${BOOT_2_DOCKER_HOST_IP}:"'{{ (index $value 0).HostPort }} {{ end }}'
|
|
|
+
|
|
|
+tomcat_host_port=$(docker inspect --format="${template}" ${container_id})
|
|
|
+
|
|
|
+for line in ${tomcat_host_port} ; do
|
|
|
+ echo "${line}" >> ${work_dir}/docker_container_hosts.properties
|
|
|
+done
|
|
|
+```
|
|
|
+> 详见：[https://docs.docker.com/engine/admin/logging/overview/](https://docs.docker.com/engine/admin/logging/overview/)
|
|
|
+
|
|
|
+# 10. Docker 清理方案
|
|
|
+## 10.1. 清理
|
|
|
+```bash
|
|
|
+docker ps -a | grep 'weeks ago' | awk '{print $1}' | xargs --no-run-if-empty docker rm
|
|
|
+
|
|
|
+docker rm $(docker ps -q -f status=exited)
|
|
|
+
|
|
|
+docker images | grep "<none>" | awk '{print $3}' | xargs docker rmi
|
|
|
+
|
|
|
+docker rmi $(docker images -q -f "dangling=true")
|
|
|
+```
|
|
|
+
|
|
|
+```
|
|
|
+docker-cleanup-volumes
|
|
|
+Manage data in containers
|
|
|
+remove-orphan-images.sh
|
|
|
+Deleting images from a private docker registry
|
|
|
+delete-docker-registry-image（support v2）
|
|
|
+
|
|
|
+Cleaning up unused Docker
|
|
|
+How to remove old Docker containers
|
|
|
+Implement a 'clean' command
|
|
|
+docker-cleanup-volumes.sh
|
|
|
+https://docs.docker.com/docker-trusted-registry/soft-garbage/
|
|
|
+docker-cleanup
|
|
|
+docker-gc
|
|
|
+```
|
|
|
+> https://github.com/yangtao309/yangtao309.github.com/issues/1
|
|
|
+
|
